Simulating muscles is a complex task that requires a lot of computational power. Muscles are often simulated as viscoelastic continuous materials using high-fidelity 3D simulations based on the finite element method (FEM). This method has limitations due to the high computational costs, numerical instabilities, and loss of accuracy. Simpler methods involve using joints with motors on them for muscles, with torque and constraints applied to them.
| Characteristics | Values |
|---|---|
| Method | Joints with motors |
| Joint properties | Constraints and torque |
| Appearance | Shape-keyed mesh deformation |
| Muscle properties | Contraction velocities |
| Muscle length | Obtained from bone geometry |
| Simulation type | 3D lattices of masses and Euler beams |
| Accuracy | Balanced with robustness and computational costs |
| Simulation method | Finite element method (FEM) |
| Muscle composition | Viscoelastic continuous materials |
Explore related products
What You'll Learn
Joints with motors
This method is often used to simulate the running gait cycle. For example, a simulation might be driven by 92 musculotendon actuators of the lower extremities and torso, and include the dynamics of arm motion. This can be analysed to determine how each muscle contributes to the acceleration of the body mass centre.
However, this method does not always reach real-time. OpenSIM, for example, was not designed for real-time applications, but instead performs high-quality simulations that can be re-played for comparisons.
On the other hand, high-fidelity 3D simulations based on the finite element method (FEM) have been used to model muscles as viscoelastic continuous materials. However, these methods also have limitations, such as prohibitive computational costs and numerical instabilities.
